VPG Buildwell - 4cub.mtr Two Bin Feeder Unit

Concrete Batching Plant

1234cub.mtr Two Bin Feeder Unit

4cub.mtr Two Bin Feeder Unit

Specification
Automatic Feeder Unit (2 Bin Belt Conveyor Type)
Machine Output 10- 12 Cub. mtr/ Hour
Power 6.5HP + (RM800 or RM1050 or RM1500 or RM1850)
Weighing System Digital Load Indicator
Water System Automatic
Aggregate bins Capacity 4 cubic mtr for each bins
Aggregate Feeding System Belt Conveyor(2 nos – 3 HP each)
Over all Dimensions
Length 5087mm
Width 5450mm
Height 2090mm
Weight 2500Kgs (Approx)
